Benchtop Screw Capper Equipment For Pump Spray Bottle

Benchtop screw capper equipment for pump caps spray desktop semi automatic fully pneumatic capping machinery

Suitable for the cap screwing of different shapes of bottles in the industries of foodstuff, pharmaceuticals, daily chemical, pesticide and cosmetics etc. Its four adjustable speed motors are used respectively for cap supplying, bottle clamping, delivering and cap screwing.

It is characterized by high level of automation, outstanding stability, easy adjustment, no need of spare parts for replacing bottle types or caps, which can be done only by adjusting.

Simple adjustment can be applied to a variety of different sizes and materials of the bottle, do not need to change any parts.

Technical data

Power supply: AC220V/50Hz;
Power consumption: 60W;
Air source pressure: 5-6kg/cm2;
Cap diameter: 20-50mm;
Bottle height: 50-300mm;
Twisting force: 5-20N.m;
Percentage of damage: 0.1%;
Production capacity: 600-1800 bottle/hour;
Machine weight: 35kg;
Overall dimension: 620LX560WX770Hmm.
