Semi Automatic Portable Pneumatic Low Viscosity Liquid Filling Machine
This series filling machine is foreign advanced filling machine technology transformation and innovative products, its structure is simple and reasonable precision, easy to operate, user-friendly design more in line with the requirements of the modern enterprise.
Widely used in pharmaceutical, cosmetic, food, pesticides and special industries, is a high-viscosity fluid, paste quantitative filling the ideal equipment.
Device Features
The series filling machine structure is reasonable, model compact, reliable, accurate, easy to operate, the pneumatic part adopts power structure of Germany FESTO and Taiwan AIRTAC, SHAKO other aerodynamic components.
Material contact parts are made of 316L stainless steel material, meet the GMP certification requirements.
According to user needs within the scope of any regulation models filling volume and filling speed, high filling accuracy.
Filling head adopts anti-leakage and lifting filling device.
The main impetus for aircraft gas source, customers must bring their own air compressor equipment.
Technical Parameters
Voltage supply: 220/110V 50-60Hz
Power: 10W
Filling accuracy: ≤ ± 0.5%
Filling speed: 10-40bottles / min
Equipped with air pressure: 0.4-0 .6 MPa
With gas consumption: ≥ 0.1m3/min
Machine Weight: 40KG
Machine size: 1150x420x380mm
